ENGINE
ENGINE TYPE Single cylinder, liquid cooled, EFI 4 stroke engine
DISPLACEMENT 408.8cc
MAX. POWER OUTPUT 33hp at 7,750rpm
MAX. TORQUE 34.5Nm at 5,500rpm
FUEL SYSTEM BOSCH® EFI
TRANSMISSION CFMOTO CVT
DRIVE H-L-N-R-P + Handbrake
4WD 2WD / 4WD / 4WD Lock
DIFFERENTIAL Fixed
STEERING Power steer
CHASSIS
SUSPENSION FRONT Arched double A-arm, 210mm of travel
SUSPENSION REAR Arched double A-arm, 235mm of travel
SHOCK ABSORBER Coil spring with oil dampening
BRAKES Hydraulic disc
WHEELS 12-inch alloy
TYRES 24-inch All Terrain tyres
SIZE
DIMENSIONS 2,165 x 1,175 x 1,265mm
WHEELBASE 1,290mm
GROUND CLEARANCE 260mm
WEIGHT (DRY) 330kg
LOAD
TOW CAPACITY 612kg
CARRIER RACK CAPACITY 40kg front, 80kg rear
FUEL CAPACITY 17 L
PERSON One
OTHER
WINCH 2,500lb
TOW PACK, MIRRORS, HORN Standard fitment
COLOUR Cypress Green
WARRANTY 2 Year
