ENGINE
ENGINE TYPE V-twin, liquid cooled, 4-stroke
DISPLACEMENT 963cc
MAX. POWER OUTPUT 85hp at 7,500rpm
MAX. TORQUE 87Nm at 5,500rpm
FUEL SYSTEM EFI with two drive modes: SPORT or NORMAL
TRANSMISSION CVT
DRIVE H-L-N-R-Park
4WD 2WD/AWD/4WD with locking front differential
REAR DIFFERENTIAL Fixed
STEERING Dual mode power steering (EPS)
CHASSIS
SUSPENSION FRONT Dual A-arm independent 307mm of travel
SUSPENSION REAR Dual A-arm independent 317.5mm of travel
SHOCK ABSORBER Piggyback gas shocks with adjustable compression and rebound damping
BRAKES All 4 wheel hydraulic disc brakes
WHEELS 14 inch alloy
TYRES 27 inch 6-ply
SIZE
L x W x H 3065 x 1524 x 1870mm
WHEELBASE 2286mm
GROUND CLEARANCE 305mm
WET WEIGHT 675kg
LOAD
TOWING CAPACITY 680kg
REAR CARGO CAPACITY 150kg
FUEL CAPACITY 37L
PERSON 2
OTHER
COLOUR Magma Red or Tundra Grey
WINCH Yes, 3500lb
WARRANTY 12 Month Warranty
