ENGINE
ENGINE TYPE Turbocharged 3-clyinder, 4-stroke, liquid cooled, DOHC
DISPLACEMENT 998cc
MAX. POWER OUTPUT 154hp at 7,750rpm
MAX. TORQUE 145Nm at 7,000rpm
FUEL SYSTEM BOSCH EFI, with three power modes
TRANSMISSION CVT
DRIVE H-L-N-R-Park
4WD 2WD / 4WD / 4WD lock
STEERING Four-mode progressive power steering (EPS)
CHASSIS
FRONT SUSPENSION High clearance double A-arm independent, 430mm of travel
REAR SUSPENSION Trailing arm independent 508mm of travel
SHOCK ABSORBER FOX® QSE shocks, three adjustable suspension modes: Soft, Medium, Firm
BRAKES Hydraulic disc
WHEELS 14-inch alloy wheels, Black
TYRES 30 x 10-inch R14 AT tyres
SIZE
L x W x H 4,039 x 1,625 x 1,740mm
WHEELBASE 3,277mm
GROUND CLEARANCE 356mm
WEIGHT 977kg (dry)
LOAD
PAYLOAD CAPACITY 400kg
FUEL CAPACITY 45L
PERSON 4
OTHER
COLOUR Lava Orange or Nebula Black
WINCH 4,500lb electric winch
WARRANTY 12 Month Warranty
