ENGINE
ENGINE TYPE V-twin, liquid-cooled four-stroke
DISPLACEMENT 963cc
MAX. POWER OUTPUT 90hp at 7,500rpm
MAX. TORQUE 85Nm at 5,500rpm
FUEL SYSTEM Bosch EFI with three power modes, SPORT, NORMAL or WORK
TRANSMISSION CFMOTO CVT
DRIVE H-L-N-R-Park
4WD 2WD/4WD with locking front differential
REAR DIFFERENTIAL Limited slip (LSD)
DOWNHILL ASSIST Electronic assist hill descent control (DAC)
STEERING Adjustable three level power steering (EPS)
CHASSIS
SUSPENSION Front: Dual A-arm independent 230mm of travelRear: Trailing arm independent 236mm of travel
SHOCK ABSORBER Piggyback gas shock absorbers with compression/rebound adjustment
BRAKES All four hydraulic disc brakes
WHEELS 14-inch alloy
TYRES 27-inch CST Clincher
SIZE
L x W x H 2435 × 1282 × 1465mm
WHEELBASE 1480mm
GROUND CLEARANCE 300mm
WET WEIGHT 518kg
LOAD
TOWING CAPACITY 800kg
CARRY CAPACITY 45kg front / 90kg rear
FUEL CAPACITY 26L
PERSON 2
OTHER
COLOUR Desert Tan
WARRANTY 2 Year Warranty
WINCH 3500lb with nylon rope
